| The main technical indicators： |
| 额定电压 Rated Voltage |
250V AC.DC |
使用导线范围 Wire Range |
AWG #28～#22 |
| 额定电流 Rated Current |
3A AC.DC |
适应基板厚度 P.C.board Thickness |
1.6mm |
| 接触电阻 Contact Resistance |
≤0.01Ω |
耐压 Winthstand Voitage |
1000V·AC |
| 绝缘电阻 Insutation esistance |
≥1000MΩ |
带有锁紧机构 With locking arm |
| 温度范围Temp.range for usage |
-25～+85℃ |
适用机型 |
音响、VCD、电脑 |
| 外壳材料 Material |
UL94V_O尼龙66（PA66） |
Suitable for |
acoustics,VCD,computers | |
|
|
